LumiBar-26-3090-H6 Nichia LED Module 4000K CRI90 TriGain 1160lm
The LumiBar-26-3090-H6 is an ultra-high-efficacy, rigid linear LED light engine engineered for specification-grade commercial, medical, and architectural luminaires where superior energy efficiency and natural color rendering must go hand in hand.
- 26 genuine Nichia H6 Series LEDs with TriGain narrow-band red phosphor technology for high efficacy at CRI 90+
- Pure neutral white 4000 K color temperature
- High color rendering index: CRI 90+ with 3-Step MacAdam ellipse binning for batch-to-batch color uniformity
- High luminous output: up to 1160 lm per 11 in module (approx. 1265 lm per foot equivalent)
- Exceptional energy efficiency: approx. 193 lm/W luminous efficacy at just 6 W module power
- Constant-current operation, fully dimmable via compatible constant-current LED drivers (0–10 V, DALI, or Lutron/Casambi)
- Standardized Zhaga Book 7 (IEC 63356-2) L28W2 mechanical form factor: 11 × 0.79 × 0.18 in
- Solderless push-in wire terminals for rapid, tool-free series wiring and field serviceability
- Precision engineered and Made in Germany
The LumiBar-26-3090-H6 is an ultra-high-efficacy, rigid linear LED light engine engineered for specification-grade commercial, medical, and architectural luminaires where superior energy efficiency and natural color rendering must go hand in hand. Powered by 26 genuine Nichia H6 Series LEDs featuring proprietary TriGain phosphor technology, it achieves CRI 90+ color fidelity alongside an extraordinary luminous efficacy of approximately 193 lm/W.
Built on a rigid 11 × 0.79 × 0.18 in PCB conforming to the Zhaga Book 7 L28W2 standard, this 4000 K pure neutral white module delivers up to 1160 lm from just 6 W on a constant-current circuit with a wide 120° beam angle and 3-Step MacAdam color consistency. Equipped with solderless push-in electrical terminals and requiring no additional heat sink in intended luminaire configurations, it streamlines both OEM fixture assembly and commercial luminaire retrofits.
Features of the LumiBar-26-3090-H6 Nichia TriGain rigid LED module
- 26 genuine Nichia H6 Series LEDs with TriGain narrow-band red phosphor technology for high efficacy at CRI 90+
- Pure neutral white 4000 K color temperature—learn more in our color temperature guide
- High color rendering index: CRI 90+ with 3-Step MacAdam ellipse binning for batch-to-batch color uniformity
- High luminous output: up to 1160 lm per 11 in module (approx. 1265 lm per foot equivalent)
- Exceptional energy efficiency: approx. 193 lm/W luminous efficacy at just 6 W module power
- Constant-current operation, fully dimmable via compatible constant-current LED drivers (0–10 V, DALI, or Lutron/Casambi)
- Standardized Zhaga Book 7 (IEC 63356-2) L28W2 mechanical form factor: 11 × 0.79 × 0.18 in
- Wide 120° viewing angle with tight LED pitch for uniform, dot-free light distribution behind diffusers
- Solderless push-in wire terminals for rapid, tool-free series wiring and field serviceability
- Thermally optimized rigid PCB designed to operate without an additional heat sink in standard luminaire housings
- Precision engineered and Made in Germany
- Backed by a 5-year commercial warranty
High-efficacy linear lighting for commercial, medical, and institutional spaces
Combining ~193 lm/W efficacy with CRI 90+ TriGain spectral quality, the LumiBar-26-3090-H6 is purpose-built for commercial linear luminaires, suspended office pendants, recessed architectural slots, and clinical fixtures. In hospitals, dental clinics, laboratories, corporate offices, and retail stores, TriGain phosphor technology preserves vivid reds and natural skin tones without the 15–20% lumen penalty typically associated with high-CRI LEDs. For luminaire engineering tips, explore our linear fixture design basics and CRI guide.
Commercial troffers and diffuse ceiling luminaires
For LED troffers and diffuse ceiling panels, multiple LumiBar-26-3090-H6 modules can be mounted in parallel rows (for example, two or four modules end-to-end in 2×2 ft or 2×4 ft troffer housings) behind a frosted diffuser. The tight 26-LED spacing and 120° beam angle eliminate dark zones while maximizing lumens per watt to meet strict commercial energy codes (such as ASHRAE 90.1 and Title 24).
White-light horticulture and vertical farming
With its 4000 K broad visible spectrum, ~193 lm/W efficiency, and rigid Zhaga-compatible bar format, the LumiBar-26-3090-H6 also serves as an efficient white-light engine for controlled-environment agriculture, including commercial lettuce production and multi-tier microgreens cultivation. Growers benefit from uniform canopy light distribution, low radiant heat, and natural white visibility for accurate crop inspection. Always dimension horticultural arrays around target PPFD, DLI, and humidity protection requirements.
Built around the Zhaga Book 7 linear-module standard (IEC 63356-2)
The mechanical geometry of this LumiBar module is engineered around the Zhaga Book 7 standard for linear and square LED modules (published internationally as IEC 63356-2), conforming to the L28W2 form-factor category (11 × 0.79 × 0.18 in actual PCB dimensions within the 11.02 in × 0.79 in standardized envelope). Zhaga Book 7 defines standardized mechanical outlines, mounting-hole positions, thermal interface planes, and optical keep-out zones so luminaire manufacturers and OEMs can design housings, reflectors, and diffusers around an open global industry standard rather than a proprietary PCB footprint.
Because the entire LumiBar family scales across the modular Zhaga Book 7 length grid—L14W2 (5.51 in class), L28W2 (11.02 in class), and L56W2 (22.05 in class)—fixture builders can create multiple luminaire lengths (such as 1 ft, 2 ft, 4 ft, and 8 ft linear fixtures) using a single standardized mechanical cross-section and mounting architecture. Its standardized Zhaga mounting holes and end-to-end butt-joint geometry allow seamless continuous linear arrays without dark shadow gaps at module junctions.
In accordance with Zhaga Book 7, these modules are non-integrated LED light engines operated from a separate external constant-current LED driver, ensuring future-proof serviceability and effortless component upgrades over the life of the luminaire. While Zhaga Book 7 guarantees mechanical and photometric envelope interoperability across compliant modules, electrical operating points (drive current and forward voltage), luminous flux, and efficacy remain product-specific—so always verify driver current, voltage window, and thermal limits when specifying or replacing modules.
Constant-current electrical integration
The LumiBar-26-3090-H6 operates from an external constant-current LED driver rather than a 12 V or 24 V constant-voltage supply. Integrated solderless push-in terminals enable fast series connections along multi-module luminaire channels without soldering, while the rigid PCB ensures repeatable mechanical alignment and thermal stability.
Who we are and our German quality promise
With over 20 years of specialized experience in LED technology, we engineer and manufacture professional LED strips, modules, and custom light engines in Germany. Our rigid and flexible LED light engines are produced in our state-of-the-art, ISO 9001, ISO 14001, and ISO 45001 certified German LED manufacturing and Reel-to-Reel (R2R) production facility, utilizing automated DEK solder paste printing with HawkEye optical inspection and precision <0.4 mil (<0.0004 in) laser/inkjet batch traceability to guarantee unmatched mechanical durability, honest datasheet ratings, and batch-to-batch consistency.
Whereas low-cost commodity LED strips and boards often suffer from rapid lumen depreciation—losing up to 60% of their brightness within 10,000 hours—and deliver under 80 lm/W in real-world operation, our German-engineered LumiBar modules combine top-tier LEDs from world-leading manufacturers with precision PCB engineering to deliver three to five times higher effective illumination and dependable long-term performance. Beyond our ready-to-ship portfolio, we support OEMs, luminaire manufacturers, and commercial project teams with custom PCB layouts, specialized spectra, prototyping, and full-scale series production. Learn more about Lumistrips and our German LED manufacturing capabilities.
| SKU | 38558 |
|---|---|
| Weight brut (g) | 30.000000 |
| Colour | Neutral White |
| Colour Temperature | 4000K |
| Colour Rendering Index | 90 |
| Luminous Flux per meter | 4100 |
| Bright like (W) | 342 |
| Luminous Flux Typ (lm) | 1160 |
| Energy Class 2022 | A |
| Viewing Angle | 120° |
| Warranty (months) | 36 |
| Manufacturer Product Code | 38558 |
| Product Family | Lumibar3090 |
| Strip Type | Rigid |
| LEDs number per sales unit | 26 |
| Dimensions: Length (cm) | 28 |
| Dimensions: Width (mm) | 20 |
| Dimensions: Height (mm) | 1.55 |
| Brand | Lumistrips |
| Manufacturer Part Number | 4062986002474 |
| Forward Voltage Typ (V) | 37.58 |
